500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min

I'm Online Chat Now
China INNOVATION AUTOMATIC CO.,LTD certification

500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min

500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min
500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min

Large Image :  500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min Get Best Price

Product Details:
Place of Origin: China
Brand Name: inntronic
Model Number: INCW-DJ220
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 100pcs per month
Detailed Product Description
Model: INCW-DJ220 Maximum Capacity: 500g(custom)
Weighing Range: 5g-500g(custom) Maximum Precision: ±0.5g
Minimum Scale: 0.5g Sorting Speed: 50~120piece/min

maximum capacity 500g(custom) INCW-DJ220 Grade Selection on line Check weigher 200g 0.1g



High Durability Online Checkweigher Maximum Capacity 500g Custom







1. Work principle and process:


When the product passes the conveyor belt through a seafood weight classifier scale, the weighing sensor on the scale will dynamically monitor the weight of the product and transmit the weight of the product to the control system of the seafood weight grader, and the system determines which weight range of the product is in the system. The control system of the seafood weight classifier gives the category of the goods and transfers the data to the sorting mechanism, which is sorted by the sorting mechanism. Goods. At the same time, the machine is compared with the original standard weight value and the upper and lower limit values, and the qualified products and overweight and heavy products are automatically sorted out.



model INCW-DJ220(level)
maximum capacity 500g(custom)
Weighing range 5g-500g(custom)
Maximum precision ±0.5g
Minimum scale 0.5g
Sorting speed 50~120piece/min
Nominal length 300mm(custom)
Nominal width 220mm(custom)
sorting grade 3~12(optional)
shape size length 2850mm(custom)
width 750mm(custom)
height 1350±50mm(custom)
Operating interface Taiwan weinview 10 inch color multi-function LCD touch screen
Operation mode Touch operation
Preset product 200
Zero point tracking Automatic zero point tracking
Automatic zero point tracking Buzzer, alarm lamp, alarm stop (custom)
Optional culling device Push rod type, air blowing type, pendulum rod type,
External interface USB interface (for storing data, optional), RS232 (optional)
Power Supply AC220V 50Hz
power 500W(custom)
Machine structure Reinforcement of stainless steel (SUS304)
Protection grade IP65 dust proof and waterproof standard
Applicable environment 0 C -40 C (to ensure accuracy, temperature change should not exceed + 5 C /h).
External gas source 0.6-1mpa
Pressure interface - 8mm (optional)
remark 1. the attributes and usage environments of the tested products are different, and the actual detection speed and accuracy are different.
More than 2. of the machine specifications are standard, other sizes and special requirements can be customized.



500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 0500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 1500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 2500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 3



500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 4

500g 0.5g Automatic Check Weighing Machines High Speed Checkweigher 120pcs/Min 5
